Full Kit 580 watt JINKO Double Glass Solar Panels with Anodized Aluminium Alloy Frame

Large Image : Full Kit 580 watt JINKO Double Glass Solar Panels with Anodized Aluminium Alloy Frame

Product Details:

Place of Origin:	Anhui
Brand Name:	Jinko
Model Number:	78HL4-BDV

Payment & Shipping Terms:

Minimum Order Quantity:	500000 watts
Price:	$0.10/watts 500000-999999 watts

Contact Now

Full Kit 580 watt JINKO Double Glass Solar Panels with Anodized Aluminium Alloy Frame

Description

Cell Size:	182mmx182mm	Type:	Half Cell, Bifacial, Double-glass, N-TYPE
Panel Dimensions:	2465113430mm	Panel Efficiency:	22.7%, 22.7%
Product Name:	Solar Panel 78HL4-BDV (615W-635W)	Warranty:	25 Years
No. Of Cells:	156(2*78)	Cell Type:	N Type Mono-crystalline
Junction Box:	IP68 Rated	Front Glass:	2.0mm,Anti-Reflection Coating
Certificate:	CE TUV	Frame:	Anodized Aluminium Alloy
Power Tolerance:	0-+3%

Product Description

Specification

SPECIFICATIONS(STC)
Module Type	JKM615N-630N-78HL4-V
Maximum Power (Pmax)	615Wp	620Wp	625Wp	630Wp	635Wp
Maximum Power Voltage (Vmp)	46.81	46.97	47.14	47.30	47.46
Maximum Power Current (Imp)	13.14	13.20	13.26	13.32	13.38
Open-circuit Voltage (Voc)	56.25	56.40	56.55	56.70	56.86
Short-circuit Current (Isc)	13.80	13.86	13.92	13.98	14.04
Module Efficiency STC (%)	22.00	22.18	22.36	22.54	22.72
Operating Temperature(℃)	-40℃~+85℃
Maximum system voltage	1000/1500VDC (IEC)
Maximum series fuse rating	25A
Power tolerance	0~+3%
Temperature coefficients of Pmax	-0.30%/℃
Temperature coefficients of Voc	-0.25%/℃
Temperature coefficients of Isc	0.046%/℃
Nominal operating cell temperature (NOCT)	45±2℃
