Product Details:
|
Cell Size: | 182mmx182mm | Type: | PERC, Half Cell, N-TYPE, TOPCON |
---|---|---|---|
Panel Dimensions: | 1755*1038*35mm | Panel Efficiency: | 20.6% |
Warranty: | 25years | Product Name: | Solar Panel 355~375w |
Power Tolerance: | 0~+5w | First Year Decay: | <2% |
Over One Years Decay: | <0.55% | Packaging: | 30pcs Per Pallet/180pcs Per 20' GP/780pcs Per 40° HC |
Operate Temperature: | -40℃~+85℃ | Maximum System Voltage: | DC1500V(IEC/U L) |
Maxmum Series Fuse Rating: | 20A | Junction Box: | IP68, Three Diodes |
Certificate: | TUV/CE/IEC |
Junction Box | IP68, three diodes |
No. of cells | 120 (6*20) |
Output Cable | 4mm2,+400,-200mm/±1400mmlength can be customized |
Glass | Single glass, 3.2mm coated tempered glass |
Frame | Anodized aluminum alloy frame |
Weight | 19.5kg |
Dimension | 1755×1038×35mm |
Packaging | 30pcs per pallet/180pcs per 20' GP/780pcs per 40° HC |
