Product Details:
|
Cell Size: | 182mmx182mm | Type: | PERC, Half Cell, Bifacial, Double-glass, N-TYPE |
---|---|---|---|
Panel Dimensions: | 2278*1134*30mm | Panel Efficiency: | 23.2% |
Power Tolerance: | 0~+5w | First Year Decay: | <1.5% |
Over One Years Decay: | <0.4% | Certificate: | TUV ISO PV CE |
Warranty: | 25YEARS |
Mechanical Specifications | ||
Junction Box | IP68, three diodes | |
No. of cells | 144 (6*24) | |
Output Cable | 4mm2,+400,-200mm/±1400mm,length can be customized | |
Glass | Single glass, 3.2mm coated tempered glass | |
Frame | Anodized aluminum alloy frame | |
Weight | 27.2kg | |
Dimension | 2278×1134×30mm | |
Packaging | 36pcs per pallet/180pcs per 20' GP/720pcs per 40° HC |
