Product Details:
|
Cell Size: | 182mmx182mm | Type: | Half Cell, PERC, Bifacial, Double-glass, N-TYPE |
---|---|---|---|
Panel Dimensions: | 2278*1134*30mm | Panel Efficiency: | 22.5% |
Warranty: | 25years | Product Name: | Sola Panel |
Application: | Solar Power System | Solar Cell: | A-grade |
Keyword: | Pv Module | Frame: | Anodized Aluminium Alloy |
Junction Box: | IP68 Rated | Glass: | 3.2mm Tempered Low Iron |
Cell Type: | 182mm Half Cut Cell |
Cell Orientation | 144 (6×24) |
Junction Box | IP68, three diodes |
Output Cable | 4mm2,±1200mm,length can be customized |
Glass | Dual glass, 2.0mm+2.0mm coated tempered glass |
Frame | Anodized aluminum alloy frame |
Weight | 31.8kg |
Dimension | 2278×1134×30mm |
Packaging | 36pcs per pallet /120pcs per 20'GP/720pcs per 40'HC |
