HUAWEI High Voltage LUNA2000-5-S0 400V Lithium Battery For Solar Home Storage System

Large Image : HUAWEI High Voltage LUNA2000-5-S0 400V Lithium Battery For Solar Home Storage System

Product Details:

Place of Origin:	Anhui
Brand Name:	huawei
Certification:	CE, RCM, CEC, VDE2510-50, IEC62619,IEC 60730, UN38.3
Model Number:	LUNA2000-5/10/15-S0

Payment & Shipping Terms:

Minimum Order Quantity:	5 pieces
Price:	$1,850.00/pieces 5-49 pieces

Contact Now

HUAWEI High Voltage LUNA2000-5-S0 400V Lithium Battery For Solar Home Storage System

Description

Battery Type:	LiFePO4	Output Power Range:	10~20 KWh
Dimension (LWH):	1250670150mm	Weight:	63.8/113.8/163.8KG
System Type:	Wall-mounted, Stackable	Type:	All-in-one
Communication Port:	CAN, RS232, RS485	Protection Class:	IP66
Grid Connection:	Off Grid, Hybrid Grid	Power Module Weight:	12 Kg (26.5lb)
Battery Module Weight:	50 Kg (110.2 Lb) 2	Installation:	Floor Stand (standard),Wall Mount (optional)
Operating Temperature:	-20℃~ + 55℃ (-4℉~131℉) 3	Max. Operating Altitude:	4,000 M (13,123ft.) (Derating Above 2,000 M)
Cooling:	Natural Convection	Noise Emission:	<29 DB
Scalability:	Max. 2 Systems In Paralleloperation

Product Description

Specification

Technical Specification	LUNA2000-5-50	LUNA2000-10-S0	LUNA2000-15-S0
Performance
Power module	LUNA2000-5KW-CO
Number of power modules	1
Battery module	LUNA2000-5-E0
Battery module energy	5 kwh
Number of battery Modultes	1	2	3
Battery usable energy	5 kwh	10 kwh	15 kwh
Max.output power	2.5 kW	5 kW
Peak output power	3.5 kw,10s	7kw,10s
Nominal voltage(uingle phane system	450V
Operating voltoge range (single phase system)	350-560V
Nominal voltage(three phase system)	600V
Opurating valtage range(three phase system)	600-980V
Communication
Dimension (WDH)	670150600(26.45.923.6 inch)	670150960mm(26.45.937.8 inch)	6701501320mm(26.45960.0 inch)
Weight(Floor stand toolrit incuded)	63.8 kg(140.71b)	113.8kg(250.9 1b)	163.8 kg(361.1 b)
Power module dimension (WDH)	670150240mm(26.45.99.4 inch)
Power module weight	12 kg (26.5 lb)
Battery module dimension (WDH)	670150360mm(26.45.914.0 inch)
Battery module weight	50kg(110.21b)
Instaltation	Floor stand(standard),Wait mount (optional)
Operating temperature	-10℃~+55℃(-40F~1310F)2
Max,operating altiude	4.000m(13,123t)(Derating above 2.000 m)
Environment	Indoor/ Outdoor
Retative humidity	5%-95%
Cooling Naturd convection Protection rating	1P 66
Noise emssion	<29 dB
Cell technology	Lithium-iron phosphate(LiFePO4)
Scalability	Max.2systerns in parallet operation
Compatibte lnverters	SUN2000-364/5.58F10KTL-MOSUN2000-3/4/5/6/8/10KTL-M15UN2000273136814/46/5/6XTL-L1.
Standard Compliance(more available upon request)
Certificates	CERCMCECVDE2510-50IEC626191EC60730,UN38.3
Ordering and Deliverable Part
Product ordering model	LUNA2000-5KW-CO,LUNA2000-5-E0,LUNA2000 Wal Mounting Bracket
