Deye Hybrid Inverter On Grid Off Grid 3 Phase 8KW 12KW SUN-12K-SG04LP3-EU-EU Inverters

Large Image : Deye Hybrid Inverter On Grid Off Grid 3 Phase 8KW 12KW SUN-12K-SG04LP3-EU-EU Inverters

Product Details:

Place of Origin:	Anhui
Brand Name:	Deye
Model Number:	SUN-5/6/8/10/12 K-SG04LP3-EU

Payment & Shipping Terms:

Minimum Order Quantity:	2 sets
Price:	$1,999.00/sets 2-9 sets

Contact Now

Deye Hybrid Inverter On Grid Off Grid 3 Phase 8KW 12KW SUN-12K-SG04LP3-EU-EU Inverters

Description

Input Voltage:	160~800Vdc	Output Voltage:	220/380, 230/400Vac
Output Current:	45A	Output Frequency:	50/60Hz
Output Type:	Three Phase	Size:	422/658/281mm
Type:	DC/AC Inverters	Inverter Efficiency:	≥99.9%
Certificate:	CEI,VDE,NRS,IEC	Warranty:	5 Years
Weight:	45/33.6KG	Product Name:	Solar Inverter
Application:	Hybrid Solar Power System	Battery Type:	Lead-acid Or Lithium-ion
Protection:	IP65	Ambient Temperature:	-25~60℃
Battery Voltage Range (V):	40~60V

Product Description

Specification

Model	SUN-8K-SG04LP3	SUN-10K-SG04LP3	SUN-12K-SG04LP3
Battery Input Data
Battery Type	Lead-acid or Li-lon
Battery Voltage Range (V)	40~60V
Max. Charging Current (A)	190A	210A	240A
Max. Discharging Current (A)	190A	210A	240A
Charging Curve	3 Stages / Equalization
External Temperature Sensor	Optional
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	10400W	13000W	15600W
Rated PV Input Voltage (V)	550V (150V~800V)
MPPT Range (V)	200V-650V
Start-up Voltage (V)	160V
Full Load DC Voltage Range	350-650
PV Input Current (A)	13+13	26+13
No.of MPPT Trackers	2
No.of Strings Per MPPT Tracker	1+1	2+1
AC Output Data
Rated AC Output and UPS Power (W)	8000W	10000W	12000W
Max. AC Output Power (W)	8800W	11000W	12000W
Peak Power (off grid)	2 times of rated power, 10 S
AC Output Rated Current (A)	12A	15A	18A
Max. AC Current (A)	18A	23A	27A
Max. Continuous AC Passthrough (A)	50A
Output Frequency and Voltage	50/60Hz; 230/400Vac (Three phase)
Grid Type	Current Harmonic Distortion
Current Harmonic Distortion	THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency	97.60%
Euro Efficiency	97.00%
MPPT Efficiency	99.90%
Protection	PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Output Over Voltage Protection
Surge protection	DC Type II / AC Type II
Certififications and Standards
Grid Regulation	IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1
Safety EMC / Standard	IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12
General Data
Operating Temperature Range (℃ )	-25~60℃ , >45℃ Derating
Cooling	Smart cooling
Noise (dB)	<30 dB
Communication with BMS	RS485; CAN
Weight (kg)	36.8
Size (mm)	422W×658H×281D
Protection Degree	IP65
Installation Style	Wall-mounted
Warranty	5 years
