3Kw 5Kw 10Kw 15Kw Solar On Grid Inverter with Pure Sine Wave Output and Single Type

Large Image : 3Kw 5Kw 10Kw 15Kw Solar On Grid Inverter with Pure Sine Wave Output and Single Type

Product Details:

Place of Origin:	Anhui
Brand Name:	Growatt
Model Number:	Off Grid Inverter

Payment & Shipping Terms:

Minimum Order Quantity:	5 sets
Price:	$355.00/sets 5-49 sets

Contact Now

3Kw 5Kw 10Kw 15Kw Solar On Grid Inverter with Pure Sine Wave Output and Single Type

Description

Input Voltage:	120-450V	Output Voltage:	230Vac±5%
Output Frequency:	50/60hz	Output Type:	Single, Pure Sine Wave
Size:	460/395/132mm	Type:	DC/AC Inverters
Inverter Efficiency:	99.9%	Certificate:	CE
Warranty:	2 Years	Weight:	13.5kg
Application:	Off Grid Solar System	Battery Type:	Lead Acid \ Lithium \ Gel
Protection:	IP66	Output Voltage Waveform:	Pure Sine Wave
Output Voltage Regulation:	230Vac±5%

Product Description

Specification

Datasheet	SPF 3000TL HVM	SPF 5000TL HVM
Battery Voltage	48VDC	48VDC
INVERTER OUTPUT
Rated Power	3000VA/3000W	5000VA/5000W
Parallel Capability	No	Yes, 6 units
AC Voltage Regulation(Battery Mode)	230VAC ± 5% @ 50/60Hz	230VAC ± 5% @ 50/60Hz
Surge Power	6000VA	10000VA
Efficiency (Peak)	93%	93%
Waveform	Pure sine wave	Pure sine wave
Transfer Time	10ms (For Personal Computers); 20ms (For Home Appliances)
SOLAR CHARGER
Maximum PV Array Power	1500W	45000W
MPPT Range @ Operating Voltage	30VDC ~ 80VDC	60VDC ~ 115VDC
Maximum PV Array Open Circuit Voltage	102VDC	145VDC
Maximum Solar Charge Current	50A	80A
Maximum Efficiency	98%	98%
Standby Power Consumption	2W	2W
AC CHARGER
Maximum AC Charge Current	30A	60A
AC Input Voltage	230VAC	230VAC
Selectable Voltage Range	170-280 VAC ( For Personal Computers); 90-280 VAC (For Home Appliances)
Frequency Range	50Hz/60Hz (Auto sensing)	50Hz/60Hz (Auto sensing)
PHYSICAL
Dimension (D/W/H) in mm	130/345/400	130/350/450
Net Weight (kgs)	8.5	11.5
OPERATING ENVIRONMENT
Humidity	5%-95% Relative Humidity (Non-condensing)
Operating Temperature	0℃~55℃
Storage Temperature	-15℃~60℃

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

To date, millions of families and businesses across the world are using Growatt's all-scenario products and solutions to power their homes and facilities. We work with thousands of local partners to establish robust distribution and logistics networks, ensuring convenient access to our advanced product portfolios for global customers. Together, we strive to make a big difference in driving the world's energy transformation.

FAQ

Q1: How to install and use the solar inverter?
A1: We have the English teaching manual and videos; All the videos about every step of machine Disassembly, assembly, operation will be sent to you.
Q2: What if I don't have import experience ?
A2: We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep. Any way, we will help you choose the most suitable shipping service.
Q3:Can you provide the free shipping to sea port ?
A3:Yes, we provide the free shipping to your convenient sea port.If you have agent in China, we can also ship it to them for free.
Q4: How is your technical support?
A4: We provide online service through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you video call anytime, our engineer will also go to oversea help our customers if necessary.
Q5: How can I make sure it's a secure transaction ?
A5: Alibaba can protect buyers' interest, all of our transation will go through alibaba platform.As you do the payment, the money will go directly to Alibaba bank account.After we send your the items and you comfirm the detailed information, Alibaba will release us the money.
Q6: Can you get the the solar inverter customized for us ?
A6: Of course, brand name, machine color, designed unique patterns available for customization.
Q7:How to become your agent?
A7:Contact us through Alibaba, we will give you the best price and look forward to your greetings.
Q8:What can you provide?
A8:Residential/Home solar system, Rooftop solar power station, Large-scale ground-mounted solar power station,
Agriculture-complementary Solar Power Station, Aquaculture-complementary Solar Power Station.
