540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm

I'm Online Chat Now

540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm

540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm

Large Image :  540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm

Product Details:
Place of Origin: Anhui, China
Brand Name: Sunman
Model Number: 520W
Payment & Shipping Terms:
Minimum Order Quantity: 5000 watts
Price: $0.35/watts 5000-499999 watts

540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm

Description
Cell Size: 166mmx166mm Panel Dimensions: 2246x1197x2mm
Panel Efficiency: 20.4% Product Name: Flexible Solar Panles
Type: Flexible Keyword: Flexiable Solar Panel
OEM Order: Support Max -Power: 430W/520W
Connector: MC4

Product Description
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 0
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 1
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 2
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 3
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 4
Specification
ELECTRICAL CHARACTERISTICS
STC
GC-F2-520W
Maximum Power(Pmax)
520
Maximum Power Voltage (Vmp)
42.3
Maximum Power Current (Imp)
12.31
Open-circuit Voltage (Voc )
49.5
Short-circuit Current (Isc )
13.56
Module Efficiency (%)
19.3
Operating Temperature
-40℃——85℃
Maximum System Voltage
1500V DC (IEC)
Maximum Series Fuse Rating
25A
Application Class
Class A
Power Tolerance
0/+5 W
STC:Irradiance 1000W/㎡,Cell temperature 25℃ , AM=1.5.
Tolerances of Pmax,Vdc and Isc are within ±5%
NMOT
GC-F2-520W
Maximum Power(Pmax)
429.2
Maximum Power Voltage (Vmp)
41.8
Maximum Power Current (Imp)
10.26
Open-circuit Voltage (Voc )
49.8
Short-circuit Current (Isc )
10.82
NMOTL:Irradiance 800W/㎡, Ambient temperature 20℃,
AM=1.5, Wind speed 1 m/s
MECHANICAL CHARACTERISTICS
Solar Cell
Monocrystalline Silicon(182mm half cell)
No.of Cells
144(12x12)
Module Dimensions
2246x1197x2 mm
Weight
8.6kg
Backsheet
White
Frame
Frameless
J-box
IP 68 Rated
Output Cables
Photovoltaic Technology Cable 4.00 2 , (+)450/(-)450 mm
Connector
MC4 Compatible
Details Images
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 5
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 6
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 7
Packing & Delivery
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 8
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 9
540W 545W 550W 560W Best Solar Panels for Solar System Module Cell size 166mmx166mm 10
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
