EER 2-4 Household 9000 BTU Solar Powered Deye Air Conditioner For Hybrid Mini Split

Large Image : EER 2-4 Household 9000 BTU Solar Powered Deye Air Conditioner For Hybrid Mini Split

Product Details:

Place of Origin:	Anhui
Brand Name:	Deye
Model Number:	12000btu ACDC (DGWG2-ACDC-12K)

Payment & Shipping Terms:

Price:	$820.00/sets 1-49 sets

Contact Now

EER 2-4 Household 9000 BTU Solar Powered Deye Air Conditioner For Hybrid Mini Split

Description

Application:	Household	Cooling/Heating:	Cooling/Heating
Capacity (btu):	>12001	EER:	2-4
Power (W):	3510(900-3900)	Power Type:	DC
Voltage (V):	208V-240V	Timer:	Yes
Remote Control:	Yes	Maximum Airflow Rate:	540m3/h
Outdoor Unit(Dimension):	802564323mm	Indoor Unit(Dimension):	840205295mm
Rated Heating(Power Input):	1170(190-1700)w	Rated Heating(Capacity):	4100(1000-4500)w

Product Description

Specification

9000 12000 18000 24000 BTU AC Solar Powered Air Conditioner DC Off Grid Solar Air Conditioner Hybrid Mini Split For Home
Model			Unit	12000btu	18000btu	24000btu
Model			Unit			DGWG2-ACDC-12K	DGWGV-ACDC-18K	DGWGV-ACDC-24K
Climate Type	Tropical			T3/T1
Application area			m2	12-20	20-30	30-42
Power Supply	AC Power	Ph-V-Hz	1Ph 208V-240V/50-60HZ
		DC Power (PV in Series)	V	80-380V
		DC Power Current	A
Adviced Solar Panel			Pcs	(3-4)*330W in series	(3-6)*330W in series	(3-8)*330W in series
Rated Cooling	Capacity(T1)	W	3510(900-3900)	5070(1200-6000)	6450(1800-7900)
		Power input(T1)	BUT	12000(3000-13300)	17300(4100-20400)	22000(6100-27000)
		Power input(T1)	W	940(190-1270)	1400(220-2100)	1790(300-3200)
		Capacity(T3)	W	2910	4290	5130
		Capacity(T3)		BTU	9900	14700	17500
		Power input(T3)	W	1050	1630	1940
Rated Heating	Capacity	W	4100(1000-4500)	6100(1200-6800)	7800(1800-9100)
	Capacity			BTU	14000(3000-15300)	20800(4100-23000)	26600(6100-31000)
		Power input	W	1170(190-1700)	1770(220-2500)	1770(300-3500)
T1 EER (W/W)/ (BTU/W)			/	3.75/12.75	3.60/12.35	3.60/12.30
T3 EER (W/W)/ (BTU/W)			/	2.75/9.45	2.65/9.00
COP (W/W)/ (BTU/W)			/	3.50/11.95	3.45/11.75	3.45/11.75
Dehumidification capacity			L/h	1.3	1.7	2.5
Compressor	Model	/	WHP04200	WHP05600	5RD198
		Model	/	2xRotary Inverter
		Model	/	Highly			Panasonic
Indoor fan motor	Model	/	BLDC-15W	BLDC-45W
Indoor fan motor		Speed(Turbo/Hi/Mi/Lo)	r/min	1300/1200/1100/950	1050/950/850/750	1350/1250/1150/1000
Indoor air flow(Turbo/Hi/Mi/Lo)			m3/h	540/485/435/350	540/485/435/350	1290/1180/1070/900
Indoor noise level (Turbo)			m3/h	≤42.5	≤46	≤50
Indoor unit	Dimension(W×H×D)	mm	840×205×295	1080×330×237
		Packing (W×H×D)	mm	920×290×360	1140×300×382
		Net weight/Gross weight	Kg	9.0/12.5	15.0/18.5
Outdoor fan motor	Model	/	BLDC-40W	BLDC-55W	BLDC-75W
Outdoor fan motor		Speed	r/min	880			850
Outdoor air flow			m3/h	2100	2200	3500
Outdoor noise level			dB(A)	≤52	≤55	≤58
Outdoor unit	Dimension(W×H×D)	mm	802×564×32	802×564×323	910×622×405
		Packing (W×H×D)	mm	910×622×405	910×622×405	1006×755×418
		Net/Gross weight	Kg	33.5/37.5	37/42.0	50/54.5
Refrigerant type			/	R410A
Max Design pressure			MPa	4.3/1.5
Refrigerant copper pipe	Gas side/Liquid side (inch)	inch	3/8 1/4	1/2 1/4
		Max. refrigerant pipe length	m	15	20	25
		Max. difference in level	m	8	10
Drain pipe size			mm	16
Refrigerant connction copper pipe length			m	3	4
Connection wire length			m	4	5
Electronic Expansion Valve			/	Yes
Loading QTY 40" Hq/ 20"GP			Sets	200/85	160/75	115/50
